Cellphone camera frame production line
Flat uncoiler
Straightener
NC servo feeder
Thickness: 0.2mm
Steel Coil Strip Flattener
Company Information
Shenzhen Fanty Machinery Equipment Co., Ltd is a supplier of automotive machines. Our main product is punching coil handing equipment and systems, like uncoiler, straightener, feeder, 2 in 1 uncoiler-straightener, 3 in 1 uncoiler-straightener-feeder, high speed press machine, precision press machine, punching upload, punching transfer etc. We have more than 18 years of experiences in metal stamping peripheral automation equipment.
Our factory has been using Japanese and German technology, and has high standards in the selection of parts. For the assembly process and spare parts, we insist to accord with original design standards and infiltrated into each of our manufacturing processes.
Steel Coil Strip Flattener Introduction
It's hard to produce good quality products if the roll material does not clear up the inner stress. The only way to make the better electric product is go through the steel coil strip flatter to remove the inner stress. After flattening, material can be corrected upward or downward of the flat.
Steel coil strip flattener machine is an equipment to do flatten sheets. It can be used in the various kind of production line.
High performance and precision steel coil strip flatter machine is engineered to maximize your productivity. All coil strip flattener are designed to remove coil set and provide smooth payout of material that translates into improved feeding efficiency and accuracy.
Steel Coil Strip Flattener Specification
| Item | TL-200 | TL-300 | TL-400 | TL-500 | TL-600 |
Coil width | 200mm | 300mm | 400mm | 500mm | 600mm |
Steel plate thickness | 0.4-2.2mm | ||||
Feed speed | 16m/min | ||||
Pinch and feed roller | Pinch roller: Ø60mm*2pcs Feed roller: Ø80mm*2pcs | Pinch roller: Ø70mm*2pcs Feed roller: Ø98mm*2pcs | |||
Flattening roller | Ø50mm*7 | Ø60mm*7 | |||
Feeding direction | From left to right | ||||
Flattening roller adjust method | Four points adjust separately | ||||
Others | Other sizes also available, please contact us for more information | ||||
Steel Coil Strip Flattener Features
1) Individual use, or run with de-coiler or double head de-coiler for better performance. Be able compatible with other feeders
2) Adopts Japanese electromagnetic touch system and electronic components, low malfunction and long lifespan
3) Bottom gear drive, roller adjusted by hand wheel
Package and Lead Time
Package: Well wrapped plywood boxes or container.
Lead time: about 7-14days.
FAQ
Q: What is the term of payment?
We accept T/T and L/C Payment.
Q: What is the term of delivery?
EXW, FOB, CFR, CIF.
Q: Do you accept customized order?
Yes, we can produce special machine according to customer request.
Q: Do you inspect all your goods before delivery?
Yes, we 100% inspect machine before delivery.
Q: How soon can I get a price quote?
For most standard machine and projects, once we get your detail information of coil thickness, coil width, coil weight and feeding speed, we can provide you with a price quote within 24 hours.
